Benetech Vibration Meter GM63B
৳ 18,000.00
Specification
| Vibration pickup: | Piezoelectric ceramic accelerometer (shear-type) |
| Measurement range of acceleration: |
0.1~199.9m/s peak |
| Measurement range of velocity: |
0.1~199.9mm/s rms |
| Measurement range of displacement: |
0.001~1.999mm p-p Velocity and displacement range is limited by acceleration199.9m/s² |
| Measurement accuracy: | ±5%±2digits |
| Measurement frequency range of acceleration: |
10Hz～1KHz (LO) 1KHz～15KHz (HI) |
| Measurement frequency range of velocity: |
10Hz～1KHz (LO) |
| Measurement frequency range of displacement: |
10Hz～1KHz (LO) |
| Displays update cycle: | 1 seconds |
| LCD display: | 3 1/2 digits display |
| Single output: | AC output 2 V peak (display full scale) Load impedance 10KΩor more earphones can be connected |
| Power supply: | 9V battery |
| Stand-by current: | ≤15μA |
| Operating current: | ≤25mA |
| Battery life: | 20 H continuous use |
| Auto power-off function: | Turns off automatically after 60 seconds |
| LCD backlight function: | 7 seconds |
| Operating temperature range: | 0~40℃ |
| Operating humidity range: | 30~90%RH |
| Low battery indication: | 6.4V±0.2V |
| Dimensions: | 72x35x145mm |
| Weight: | 229g (not including battery) |
| Temperature range: | -10℃~80℃ |
| Temperature accuracy: | ±2℃ |
... people are viewing this right now
Features:
- Vibration Meter possesses the following features:
1.LCD display measurement result and conditions directly
2.Measures acceleration (m/s² peak), velocity (mm/s ms),
and displacement (mm p-p)3.Selective vibration characteristic
4.Uses hi- sense of vibration sensor, measuring accurately
5.Equipped two probes (S and L) to adapt the different
measurement requirement6.Provides a magnetic probe to fit the condition uneasy hold
on by hand7.Low battery indication
8.Auto turn off function
9.LCD back light function
10.Maximum value hold function
11.Temperature unit C°/F°selection
