৳ 9.68 ৳ 8.80
UT502C Insulation Resistance Tester, with its new design, large-scale integrated circuit, and digital circuit, is utilized to measure insulation resistance, alternating voltage, and other parameters. The tester has features of complete functions, high accuracy, stable performance, and comfortable and reliable operation. The tester is used in maintenance, testing, and verification for various electrical equipment and is applicable to measure the insulation resistance of transformers, motors, cables, switches, electric appliances, etc.

UNI-T UT502C Insulation Resistance Tester

UNI-T UT502C Insulation Resistance Tester
| Specifications | Output Voltage | Measurement Range | UT502C |
| Insulation Resistance Measurement | 100V | 0.00MΩ~100MΩ | |
| 250V | 0.00MΩ~500MΩ | √ | |
| 500V | 0.00MΩ~2.00GΩ | √ | |
| 1000V | 0.00MΩ~5.00GΩ | √ | |
| 2500V | 0.00MΩ~20.0GΩ | √ | |
| Accuracy | 0.00MΩ~99.9MΩ: ±(3%+5) 100MΩ~5.00GΩ: ±(5%+5) |
||
| 0.00MΩ~99.9MΩ: ±(3%+5) 100MΩ~9.99GΩ: ±(5%+5) 10.0GΩ~20.0GΩ: ±(10%+5) |
√ | ||
| Voltage Measurement Range | AC: 30V~750V (50Hz/60Hz), ±(2%+3) | ||
| Short-Circuit Current | <2mA | ||
| Powered by | Adaptor (optional, without charging function) | ||
| 6×1.5V AA alkaline batteries | |||
| Auto Power Off | √ | ||
| Self-Lock Function | √ | ||
| Low Battery Indication | √ | ||
| Data Hold | √ | ||
| Auto Discharge | √ | ||
| Audible and Visual Alarm | √ | ||
| Overrange Indication | √ | ||
| Backlight function | √ | ||
| Altitude | ≤2000 m | ||
| Operating temperature and Humidity | 0℃~35℃,<75% RH | ||
| Storage temperature and Humidity | -20℃~60℃,<80% RH | ||
| Rating | CAT III 600V | ||
| General Characteristics | |||
| Product Color | Red + grey | ||
| Product Weight (Include batteries) |
0.6kg | ||
| Product Size | 183.5mmx115mmx74mm | ||
| Accessories | User manual *1 pcs;test lead *1 set;Alligator *1 set,Strap *1 pcs, 1.5V AA batteries *6pcs. | ||
| Standard Package | Gift box+ cloth bag | ||
| Package Quantity | Outer Carton:20pcs | ||
| Package Size | 345mmx335mmx245mm | ||
|
|
|
0% |
|
|
|
0% |
|
|
|
0% |
|
|
|
0% |
|
|
|
0% |
Features:
Industrial electrical maintenance.
Electrical panel troubleshooting.
Generator and power plant maintenance.
Motor and transformer testing.
HVAC and refrigeration systems.
Electrical wiring inspection.
Electronic circuit troubleshooting.
Commercial building maintenance.
Electrical equipment installation.
Factory and workshop maintenance.
Electrical panel and circuit breaker inspection
Transformer and generator temperature monitoring
Industrial motor and bearing inspection
HVAC and air conditioning maintenance
Compressor and pump temperature checking
Manufacturing and production facilities
Mechanical workshop maintenance
Steam pipes, valves and ventilation systems
Preventive maintenance and troubleshooting
The Megger LRCD200 series is the latest generation of combined non-tripping loop tester and RCD test instruments that provide simple, affordable and flexible test tools for electrical contractors testing energized circuits.
