UNI-T UTi120S Infrared Thermal Imager
৳ 20.00
The UNI-T UTi120S Thermal Imager is a rugged and cost-effective handheld infrared camera designed for fast, accurate temperature measurement and thermal diagnostics. With a 120×90 infrared resolution (10,800 pixels), adjustable emissivity (0.01–0.99), and a temperature measurement range of -20℃ to 400℃, it’s perfect for electrical inspection, HVAC maintenance, building diagnostics, and industrial troubleshooting.
... people are viewing this right now
Description
Key Features:
- Infrared Resolution: 120×90 (10,800 pixels) with ≤60mK thermal sensitivity.
- Temperature Range: -20℃ to +400℃ with ±2℃ / ±2% accuracy.
- Fast Measurement: <500ms response time, 0.1℃ resolution.
- Display: 2.4″ TFT LCD, 320×240 resolution.
- Modes: Thermal, thermal blending, PiP (selected models).
- Color Palettes: 6 options (Rainbow, Iron Red, White Hot, Black Hot, Lava, High-Contrast Rainbow).
- Storage: Supports 16GB TF card image storage (BMP format).
- Alarms: High/low temperature alarm with image, LED, and buzzer alerts.
- Laser Pointer & LED Light: For accurate targeting in dark environments.
- Durability: IP54 dust/water protection, 2m drop resistance.
- Battery: Rechargeable 3.7V/2600mAh Li-ion (up to 9 hours use).
- PC Software: USB data transfer for analysis and reporting.
Technical Specifications:
- Sensor: Uncooled infrared focal plane, 17μm pixel size
- Field of View (FOV): 50°(H) × 38°(V)
- Infrared Spectrum Bandwidth: 8–14μm
- Temperature Accuracy: ±2℃ or ±2% (-10℃ to 400℃)
- Image Format: BMP
- Communication: USB Type-C
- Automatic Shutdown: Selectable (5/10/30 mins), default 30 mins
- Dimensions: 236 × 75.5 × 86 mm
- Weight: ~350 g
