47 Starrett Universal Bevel (6* / 150mm)

47
Starrett Universal Bevel
6″ / 150mm

This improved Universal Bevel has both offset
and straight slots in the blade, in combination
with straight slots in the stock that allow for a
wide variety of adjustment and angle settings
that are impossible to obtain with many
ordinary bevels.
Length of the blade is 6″ (150mm), and the
stock, 3-1/2″ (90mm). The stock lies flat
on the work or paper since the head of the
clamping bolt is recessed. This tool can be set
to duplicate an angle from a master, or it may
be easily converted into a Bevel Protractor by
using this tool with the 193 Protractor.
