UT12D non-contact AC voltage detectors are widely used in the maintenance of low voltage equipments such as conductors, cables, sockets, and other electrical/electronics instruments. It is a very handy tool for electricians.

01 AC Voltage Detector-UNI-T UT12D

01 AC Voltage Detector-UNI-T UT12D
UNI-T UT12D AC Voltage Detector is a professional non-contact voltage testing instrument designed to detect the presence of AC voltage in electrical wires, cables, sockets, switches and electrical panels. It features dual voltage detection modes, audible buzzer alerts, LED visual indication and a built-in flashlight for convenient operation in dark working environments.
Suitable for electricians, electrical engineers, maintenance technicians, industrial technicians and household electrical troubleshooting.
Non-contact AC voltage detection (NCV).
Dual voltage detection: High and Low modes.
High voltage detection: 90V–1000V AC.
Low voltage detection: 24V–1000V AC.
Audible buzzer and LED indication.
Built-in LED flashlight.
Automatic power-off function.
Low battery indication.
Compact, lightweight and portable design.
Easy one-button operation.
| Specification | Details |
|---|---|
| Brand | UNI-T |
| Model | UT12D |
| Product Type | AC Voltage Detector |
| Detection Method | Non-Contact (NCV) |
| High Voltage Range | 90–1000V AC |
| Low Voltage Range | 24–1000V AC |
| Frequency | 50/60Hz |
| Voltage Indication | LED |
| Alarm | Audible Buzzer |
| Flashlight | Built-in |
| Voltage Modes | High / Low |
| Auto Power Off | Yes |
| Low Battery Indication | Yes |
| Battery | 2 × 1.5V AAA (R03) |
| Product Dimensions | 150 × 18 × 23 mm |
| Net Weight | Approx. 50g |
| Drop Test | 1 metre |
| Accessories | Batteries, English Manual |
Specifications are based on the UNI-T UT12 series documentation.
Electrical wire and cable testing.
Wall socket and switch inspection.
Electrical distribution board checking.
Industrial electrical maintenance.
Power supply troubleshooting.
Electrical equipment inspection.
Residential and commercial electrical work.
Factory and construction site maintenance.
The UT12D offers a convenient way to check for the presence of AC voltage without making direct electrical contact with the conductor. Its compact design, dual detection range and audio-visual alerts make it a practical tool for everyday electrical maintenance.
Important Safety Note: This detector only indicates the possible presence of AC voltage. Always verify that a circuit is de-energized using an appropriately rated voltage tester before touching conductors. Do not use it as the sole proof that a circuit is safe.
