৳ 3.96 ৳ 3.60
Electrical motor insulation testing.
Transformer insulation resistance checking.
Power cable insulation testing.
Generator maintenance and inspection.
Electrical panel and switchgear testing.
Industrial electrical equipment maintenance.
Telecommunication equipment testing.
Preventive electrical maintenance.

Victor VC60B+ Digital Insulation Tester

Victor VC60B+ Digital Insulation Tester
The Victor VC60B+ is designed to apply selectable DC test voltages of 250V, 500V and 1000V for checking insulation resistance. It helps identify insulation deterioration, leakage risks and potential electrical faults before they cause equipment failure.
Its digital LCD display, backlight function, data hold and automatic power-off features make testing convenient in industrial and electrical maintenance environments.
Whether you are testing electrical motors, power cables, generators or transformers, the VC60B+ provides a practical solution for routine insulation resistance testing.
Multiple Test Voltages: 250V, 500V and 1000V DC.
Digital LCD Display: Easy-to-read measurement results.
Insulation Resistance Testing: Suitable for electrical equipment and cable insulation checks.
Backlight Display: Convenient operation in low-light environments.
Data Hold Function: Holds readings for easy recording.
Low Battery Indicator: Alerts users when battery power is low.
Overload Indication: Helps identify readings beyond the measuring range.
Auto Power Off: Helps conserve battery power.
Portable Design: Convenient for field and industrial maintenance work.
| Specification | Details |
|---|---|
| Brand | VICTOR |
| Model | VC60B+ |
| Product Type | Digital Insulation Tester |
| Test Voltage | 250V / 500V / 1000V DC |
| Insulation Range | Up to 2000MΩ |
| Accuracy | ±(4% + 2 digits) |
| Display Count | 1999 |
| AC Voltage Testing | Up to 750V (model specification) |
| Backlight | Yes |
| Data Hold | Yes |
| Low Battery Indicator | Yes |
| Overload Indicator | Yes |
| Auto Power Off | Yes |
| Power Supply | 6 × 1.5V AA batteries |
| LCD Display | Digital |
Specifications are based on available VC60B+ documentation. Confirm the exact product version and manual before publishing final technical specifications.
Electrical motor insulation testing.
Transformer insulation resistance checking.
Power cable insulation testing.
Generator maintenance and inspection.
Electrical panel and switchgear testing.
Industrial electrical equipment maintenance.
Telecommunication equipment testing.
Preventive electrical maintenance.
The Victor VC60B+ is a practical choice for electrical professionals who need a dedicated insulation resistance testing instrument. Its selectable test voltage, digital measurement display and portable design make it suitable for regular electrical inspection and maintenance activities.
Safety Note: Always disconnect the equipment from its power supply before insulation testing. Verify that the circuit is de-energized, follow the manufacturer’s instructions and allow the tested equipment to discharge after testing.
Product Category: Electrical Testing Instruments → Insulation Resistance Tester
Brand: VICTOR
Supplier: Dusk Technology BD
Website: https://dusktechnology.com.bd
Recommended Image Alt Text: Victor VC60B+ Digital Insulation Resistance Tester 1000V
|
|
|
0% |
|
|
|
0% |
|
|
|
0% |
|
|
|
0% |
|
|
|
0% |
Focus Keywords:
Fluke 376 Clamp Meter
Fluke True RMS Clamp Meter Bangladesh
Fluke AC DC Clamp Meter
Fluke 376 iFlex
Digital Clamp Meter Bangladesh
Industrial Electrical Testing Equipment
Key Features:
Get the infrared troubleshooting power you need.
Industrial electrical maintenance.
Electrical panel troubleshooting.
Generator and power plant maintenance.
Motor and transformer testing.
HVAC and refrigeration systems.
Electrical wiring inspection.
Electronic circuit troubleshooting.
Commercial building maintenance.
Electrical equipment installation.
Factory and workshop maintenance.
